TI的线性稳压器IC TPS75233QPWP
信息类型：供应
TI 主页 > 半导体 > 电源管理 > 线性稳压器 > 单通道 LDO > TPS75233QPWP
德州仪器的单输出 LDO、2A、固定电压 (3.3V)、SVS、快速瞬态响应芯片 TPS75233QPWP
Fast-Transient-Response 2-A Low-Dropout Voltage Regulators
德州仪器的线性稳压器IC TPS75233QPWP的说明
The TPS752xxQ and TPS754xxQ devices are low-dropout regulators with integrated power-on reset and power-good (PG) functions respectively. These devices are capable of supplying 2 A of output current with a dropout of 210 mV (TPS75233Q, TPS75433Q). Quiescent current is 75 μA at full load and drops down to 1 μA when the device is disabled. These devices are designed to have fast transient response for larger load current changes.
Because the PMOS device behaves as a low-value resistor, the dropout voltage is very low (typically
210 mV at an output current of 2 A for the TPS75x33Q) and is directly proportional to the output current. Additionally, because the PMOS pass element is a voltage-driven device, the quiescent current is very low and independent of output loading (typically 75 μA over the full range of output current, 1 mA to 2 A).
线性稳压器IC TPS75233QPWP的特性
2-A Low-Dropout Voltage Regulator
Available in 1.5 V, 1.8 V, 2.5 V, 3.3 V Fixed Output and Adjustable Versions
Open Drain Power-On Reset With 100ms Delay (TPS752xxQ)
Open Drain Power-Good (PG) StatusOutput (TPS754xxQ)
Dropout Voltage Typically 210 mV at 2 A (TPS75233Q)
Ultralow 75-μA Typical Quiescent Current
Fast Transient Response
2% Tolerance Over Specified Conditions for Fixed-Output Versions
20-Pin TSSOP PowerPAD™ (PWP) Package
Thermal Shutdown Protection
单通道LDO芯片 TPS75233QPWP的应用APPLICATIONS-
Telecom 电信
Servers 服务器
DSP, FPGA Supplies 数字信号处理器/现场可编程阵列等的应用
TI 主页 > 半导体 > 电源管理 > 线性稳压器 > 单通道 LDO > TPS75233QPWP
德州仪器的单输出 LDO、2A、固定电压 (3.3V)、SVS、快速瞬态响应芯片 TPS75233QPWP
Fast-Transient-Response 2-A Low-Dropout Voltage Regulators
德州仪器的线性稳压器IC TPS75233QPWP的说明
The TPS752xxQ and TPS754xxQ devices are low-dropout regulators with integrated power-on reset and power-good (PG) functions respectively. These devices are capable of supplying 2 A of output current with a dropout of 210 mV (TPS75233Q, TPS75433Q). Quiescent current is 75 μA at full load and drops down to 1 μA when the device is disabled. These devices are designed to have fast transient response for larger load current changes.
Because the PMOS device behaves as a low-value resistor, the dropout voltage is very low (typically
210 mV at an output current of 2 A for the TPS75x33Q) and is directly proportional to the output current. Additionally, because the PMOS pass element is a voltage-driven device, the quiescent current is very low and independent of output loading (typically 75 μA over the full range of output current, 1 mA to 2 A).
线性稳压器IC TPS75233QPWP的特性
2-A Low-Dropout Voltage Regulator
Available in 1.5 V, 1.8 V, 2.5 V, 3.3 V Fixed Output and Adjustable Versions
Open Drain Power-On Reset With 100ms Delay (TPS752xxQ)
Open Drain Power-Good (PG) StatusOutput (TPS754xxQ)
Dropout Voltage Typically 210 mV at 2 A (TPS75233Q)
Ultralow 75-μA Typical Quiescent Current
Fast Transient Response
2% Tolerance Over Specified Conditions for Fixed-Output Versions
20-Pin TSSOP PowerPAD™ (PWP) Package
Thermal Shutdown Protection
单通道LDO芯片 TPS75233QPWP的应用APPLICATIONS-
Telecom 电信
Servers 服务器
DSP, FPGA Supplies 数字信号处理器/现场可编程阵列等的应用
